Khoom Description
Hlau yog muaj zog, ruaj, thiab muaj nyob rau hauv pua pua ntawm alloys. CNC machining steel kev pabcuam tuaj yeem pom nyob txhua qhov chaw. Tab sis rau tshuab steel kuj xav tau rau tshuab. High txiav quab yuam, tsim hluav taws xob, ua hauj lwm hardening (tshwj xeeb tshaj yog nrog stainless), thiab cov cuab yeej hnav tsim cov kev cov nyom uas hnyav nrog ib feem complexity. Peb 5-axis machining daws teeb meem ntau ntawm cov teeb meem no. Tsis muaj MOQ thiab ceev hauv Hnub rau koj cov khoom siv.
-------------------- Peb CNC Machining Peev Xwm -------------------
|
Tshwj xeebParammeters/Description |
|
|
Khoom siv |
3-axis, 4-axis, 5-axis CNC Milling; CNC tig |
|
Ua siab ntev |
+/- 0.01 hli |
|
Max Loj |
2000x1600x450mm |
|
Khoom siv |
Aluminium, Stainless hlau, tooj dag, tooj liab, Titanium, PEEK, Nylon, Acrylic, POM, ABS ... |
|
Min phab ntsa tuab |
0.5mm (hlau), 0.8mm (yas) |
|
Kev kho saum npoo |
Anodizing (ntshiab / dub / xim), hmoov txheej, Bead blasting, Plating (zinc / nickel / chrome), Passivation, txhuam, polishing |
|
Daim ntawv pov thawj |
ISO 9001 Daim ntawv pov thawj |
|
Ntau lawm ntim |
Ceev prototyping rau ntau lawm, Tsis muaj MOQ |
Common Detailed Steel rau Machining
- Stainless hlau (303, 304, 316 / L, 17-4PH)
- Cov cuab yeej hlau (A2, D2, H13)
- Alloy hlau (4140, 4340)
- Cov pa roj carbon steel (1018, 1045, A36)
- Cov hlau me me (Q235)
- Hardened hlau (HRC 38-62)
CNC Millhauv Tolerances
Peb ua raws ISO 2768 Cov Qauv rau CNC Machining
| Txwv rau Nominal Size | Plastics (ISO 2768-M) | Cov hlau (ISO 2768-F) |
| 0.5mm txog 3mm | +/- 0.1 hli | +/- 0.05 hli |
| Ntau tshaj 3mm mus rau 6mm | +/- 0.1 hli | +/- 0.05 hli |
| Tshaj 6mm mus rau 30mm | +/- 0.2 hli | +/- 0.1 hli |
| Tshaj 30mm mus rau 120mm | +/- 0.3 hli | +/- 0.15 hli |
| Tshaj 120mm mus rau 400mm | +/- 0.5 hli | +/- 0.2 hli |
| Ntau tshaj 400mm txog 1000mm | +/-0.8m | +/- 0.3 hli |
| Ntau tshaj 1000mm txog 2000mm | +/- 1.2 hli | +/- 0.5 hli |
|
Ntau tshaj 2000mm txog 4000mm |
+/- 2 hli | - |
Cov cuab yeej kuaj xyuas zoo
Ntawm XC Precision, peb ua tiag tiag ntawm qukev ntseegtswj, peb muaj tus qauvzootxheej txheem, nrog ntau yam tshuaj xyuaskhoom sivthiabkev tshaj lijQC pab neeg.
Los ntawm raw cov ntaub ntawv tuaj thiab thaum lub sij hawm machining txheej txheem rau cov khoom kawg rau shipping. Peb nruj me ntsis tswj cov khoom zoo nyob rau hauv txhua kauj ruam.
- Xyuas kom tseeb tias cov ntaub ntawv raug siv kom raug.
- Xyuas kom tseeb tias qhov ntev yog nruj me ntsis tswj nyob rau hauv tus txheej txheem siab
- Xyuas kom tseeb tias qhov zoo li nyob rau hauv qhov teeb meem zoo meej raws li cov neeg siv khoom xav tau
Txhua yam yuav tsum tau dhau qhov kev kuaj xyuas zoo thiab tom qab ntawd mus rau kev xa khoom
